Road Concrere Curb | Kerb Pavers HT400 :

Working video in Youtube : http://youtu.be/o4wDt_oYkCw

HT400 concrete curb paver is the special machine to construct road curb, with slipforming construction method, with fast construction speed, high degree of mechanization, widely used in highway and municipal road curb construction project.
Save time, labor, material and can improve work efficiency.

Technical Parameter Of Concrete Kerb Paver Of HT400:

HT400

Specifications

Features

Curb size range

Width≤600mm,height≤460mm

Is widely applicable for curbs

Parameters

Of engine set

Fuel

diesel

Single-cylinder water-cooled diesel engine, simple and reliable

Power

8kw

Output voltage

380v,3 phases

Start-up mode

Electric start

Radiating way

Water cooling

Paving speed

1-4m/min

Imported CVT (Continuously Variable Transmission), facilitate the adjustment of the most suitable paving



Concrere Curb Pavers

Concrere Kerb Pavers

Contact us

  • Skype : andyvictoryy
  • Email : andy@htenma.com
  • Mobile(whatsapp, weichat) :
    0086 18638556116
  • Factory Address :
    Gebo Development Zone, Qinhuangdao City, Hebei, China
  • Office Address :
    1701, No. 27, Future International Bldg., Business Inner Ring East 3rd Rd, Zhengzhou City, Henan Province

Comparison Between Self-propulsion And Anti-push Type

All the models of our machine is Self-propulsion Type

1 Forming Intensity : anti-push type move forward by squeezing,low intensity.
Self-propulsion Type forms curb by high frequency vibration,
max exciting force 500kN

2 Working Speed : anti-push type squeezing one time and move forward one time,speed is low and can not be adjusted.

3 Embedded Curbs : anti-push type only can make curb on the road surface,can not pave the curb embedded down the road surface.

4 Curb Appearance : the mortar bucket of anti-push type is integrated with machine,easily blocked,
separated mortar bucket (self-propulsion type) can make the curb appearance more beautiful.

5 For Commercial Concrete (plastic concrete,fed by concrete truck directly),anti-push type is not suitable for this concrete.
